TS series 5416-16E | 16Ch Network Video Recorder (NVR), 16 PoE port, H.265, up to 8MP (4K), HDMI, 112Mbps Bandwidth, 8 × SATA, 1 × eSATA

16 CH 8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P high definition PoE NVRs, which adopt the most advanced SOC technique to ensure high definition recording in each channel and realize outstanding robustness of the system. It integrates with 16 PoE network ports, support 16 CH IPC direct connection to NVR , simultaneous 16 CH playback, and 4K high definition display. The series of product can meet different security requirements of home, financial, commerce, enterprise, transportation and government, etc.
FEATURES
Support 16 CH 8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P IP input
Adopt standard H.265 and H.264 high profile compression format to get high-quality video at much lower bit rate
Intuitive and user-friendly Graphic User Interface ( GUI ), Windows style operation by mouse
Multi-mode recording: manual / timer / motion / sensor
Playback : 16 CH simultaneous playback
Search : time slice, time, event ( manual, sensor, motion ), tag search
Express and flexible backup via USB, network and so on
Pentaplex : preview, record, playback, backup and remote access
DHCP, DDNS, PPPoE network protocol and CMS supported
Remote control via IE or CMS : preview, playback, backup, PTZ and configuration
16 PoE network ports, support IPC direct connection to NVR; support PoE power supply
Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
Multi-user online simultaneously
Authorization management, log view and device status view
4K output, true high resolution display
Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
Support NAT function and QRCode scanning by mobile phone and PAD
Powerful smart phone & Pad surveillance with iOS and Andriod OS
SPECIFICATIONS
System
Compression
Standard H.265, H.264
OS
Embedded Linux
Video
Network Input
16 CH IPC input
Network Access Bandwidth
112Mbps
Network Access Format
8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P@25 / 30fps
Output
HDMI × 1 : 3840 × 2160 / 1920 × 1080 / 1280 × 1024 / 1024 × 768VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768
Audio
Network Input
16 CH IPC audio input
2-way Audio
RCA × 1
Local Output
RCA × 1
Record
Record Stream
Dual stream recording
Resolution
8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P
Mode
Manual, timer, motion, sensor
Playback
Simultaneous Playback
Max 16 CH
Search
Time slice / time / event / tag search
Smart Search
Highlighted color to display the camera record in a certain period of time, different colors refers to different record events
Function
Play, pause, FF, FB, digital zoom, etc.
Alarm
Mode
Manual, sensor, motion, exception
Input
Support IPC alarm input
Output
Support IPC alarm output
Triggering
Record, snap, preset, e-mail, etc.
Network
Interface
RJ45 10 / 100 / 1000 Mbps × 1
PoE Port
RJ45 × 16
Protocol
TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP
Mobile Device
OS
iOS, Andriod
Storage
HDD
SATA × 2, max 8T per HDD
Backup
Local Backup
U disk, USB mobile HDD
Network Backup
Yes
Port
USB
USB 2.0 × 2 ( one in the front panel and the other in the rear panel )
Remote Controller
Optional
Others
Power Supply
DC48V
Consumption
≤ 15W ( without HDD )
Dimensions (mm)
380 × 268 × 52 ( W × D × H )
Work Environment
−10 ~ 50°C, 10% ~ 90% humidity
